AEC-Q200 Qualified Products
Type
Dimensions
Inductance
DCR
Isat
Irms
Specification
L*W*H(mm)
(uH)
(mOHM)
(A)
(A)
SPA01-1003
10.3x10.5x3.0
0.8~150
5.7~871
9.0~0.7
6.5~0.51
SPA01-1004
10.3x10.5x4.0
1.0~1000
6.0~2853
12.1~0.46
10~0.45
SPA01-1005
10.3x10.5x5.0
0.68~330
5.5~815
13.5~0.75
9.5~0.73
SPA02-8028
8.0x8.0x3.1
2.5~220
22~1120
5.0~0.55
4.8~0.50
SPA02-8038
8.0x8.0x4.0
1.8~100
15.6~410
7.0~1.05
6.8~0.88
SPA02-8043
8.0x8.0x4.5
1.2~100
12.2~360
8.0~1.3
6.2~0.8
SPA02-8058
8.0x8.0x6.0
2.8~100
15~175
4.7~0.8
6.9~1.4
SPA03-1206
12.3x12.3x6.0
1.0~120000
3.1~195000
23.6~0.069
15~0.06
SPA03-1208
12.3x12.3x8.0
1.0~1000
4.07~2158
40~1.14
15.5~0.61
SPA04-1508
15x15x8.6
10~1000
14~990
14.7~1.4
7.4~0.86
SPA04-1514
15x15x14.5
2.5~1000
7.0~625
30.5~1.63
7.8~0.77
