Russian SP16-201610 Type
产品尺寸
产品参数
| Part Number | Inductance L0(uH) | DCR | Isat | Irms | ||||
|---|---|---|---|---|---|---|---|---|
| (mΩ)Typ. | (mΩ)Max. | (A)Typ. | (A)Max. | (A)Typ. | (A)Max. | |||
| SP16-201610R10M | 0.10±20% | 7 | 10 | 9 | 8.4 | 8.5 | 8 |  |
| SP16-201610R15M | 0.15±20% | 8 | 12 | 8.7 | 8 | 7.6 | 7 | |
| SP16-201610R22M | 0.22±20% | 11 | 16 | 8.2 | 7.5 | 6.9 | 6.3 | |
| SP16-201610R24M | 0.24±20% | 12 | 17 | 8 | 7.4 | 6.8 | 6.2 | |
| SP16-201610R33M | 0.33±20% | 17 | 22 | 7 | 6.5 | 5.7 | 5.3 | |
| SP16-201610R47M | 0.47±20% | 22 | 25 | 6 | 5.5 | 5.5 | 5 | |
| SP16-201610R56M | 0.56±20% | 19 | 23 | 5.5 | 5 | 6.5 | 6 | |
| SP16-201610R68M | 0.68±20% | 25 | 32 | 5.2 | 4.7 | 4.6 | 4.3 | |
| SP16-2016101R0M | 1.0±20% | 35 | 43 | 4.6 | 4.2 | 4.5 | 4.1 | |
| SP16-2016101R5M | 1.5±20% | 80 | 100 | 3.2 | 2.9 | 2.6 | 2.3 | |
| SP16-2016102R2M | 2.2±20% | 115 | 130 | 3 | 2.8 | 2.5 | 2.1 | |
| SP16-2016103R3M | 3.3±20% | 140 | 170 | 2.3 | 2 | 1.7 | 1.5 | |
| SP16-2016104R7M | 4.7±20% | 190 | 220 | 2 | 1.8 | 1.6 | 1.4 | |
| SP16-2016106R8M | 6.8±20% | 320 | 350 | 1.7 | 1.5 | 1.7 | 1.5 | |
| SP16-201610100M | 10±20% | 483 | 580 | 1.4 | 1.1 | 1 | 0.7 | |
