Automotive

Image Type Dimensions  Inductance DCR   Isat     Irms  Specification
L*W*H(mm) (uH) (mOHM) (A) (A)
SPA01-1003 10.3x10.5x3.0 0.8~150 5.7~871 9.0~0.7 6.5~0.51
SPA01-1004 10.3x10.5x4.0 1.0~1000 6.0~2853 12.1~0.46 10~0.45
SPA01-1005 10.3x10.5x5.0 0.68~330 5.5~815 13.5~0.75 9.5~0.73
SPA02-8028 8.0x8.0x3.1 2.5~220 22~1120 5.0~0.55 4.8~0.50
SPA02-8038 8.0x8.0x4.0 1.8~100 15.6~410 7.0~1.05 6.8~0.88
SPA02-8043 8.0x8.0x4.5 1.2~100 12.2~360 8.0~1.3 6.2~0.8
SPA02-8058 8.0x8.0x6.0 2.8~100 15~175 4.7~0.8 6.9~1.4
SPA03-1206 12.3x12.3x6.0 1.0~120000 3.1~195000 23.6~0.069 15~0.06
SPA03-1208 12.3x12.3x8.0 1.0~1000 4.07~2158 40~1.14 15.5~0.61
SPA04-1508 15x15x8.6 10~1000 14~990 14.7~1.4 7.4~0.86
SPA04-1514 15x15x14.5 2.5~1000 7.0~625 30.5~1.63 7.8~0.77
